Thermostatic Drying Oven
  • Thermostatic Drying OvenThermostatic Drying Oven
  • Thermostatic Drying OvenThermostatic Drying Oven

Thermostatic Drying Oven

Thermostatic drying oven is commonly used to dry glassware after washing in laboratory experiments. Drying glassware in an oven helps to remove the water residue completely and prevents any unwanted reaction caused by water droplets, which can alter results or even introduce contamination.

Model: TG-9023A
Capacity: 25L
Interior Dimension: 300*300*270 mm
Exterior dimension: 585*480*440 mm

Send Inquiry

Product Description


Climatest Symor® thermostatic drying oven achieves and maintains a temperature range suitable for drying glassware without damaging it, and ensures a thorough, quick, and hygienic drying process, thereby reducing the risks of contamination and providing precise measurement results.




















Interior Dim.










Exterior Dim.










Temperature Range

RT+10°C ~ 200°C

Temperature Fluctuation

± 1.0°C

Temperature Resolution


Temperature Uniformity

±2.5% (test point@100°C)




0~ 9999 min

Power Supply

AC220V 50HZ

Ambient Temperature

+5°C~ 40°C

Working principle/ Structure

Thermostatic drying oven adopts forced air convection system, it works by drawing in air from outside the oven and heating it with the heaters. The heated hot air is then circulated around the oven by the blower. This helps to dry products evenly. The LED controller monitors the temperature inside the oven, allowing the operator to set different temperatures. The drying process in this oven involves circulating hot air around the products to evaporate the moisture. The blower helps to uniformly spread the hot air throughout the oven, and the temperature can be adjusted to suit the products being baked.

Thermostatic drying oven is an enclosed chamber used for the drying and curing of materials. It typically consists of an insulated chamber, a heating element, a temperature controller, a timer, and a blower that circulates hot air throughout the chamber. The oven is designed to be airtight to keep good insulation, and the heater is used to increase the temperature within the chamber to a desired level. The temperature controller regulates the temperature, and the blower helps to circulate the heated air. The timer can be used to set the time of drying process.

Overall, thermostatic drying oven is designed to provide a controlled temp. environment to heat and dry samples or materials, so as to get desired results.


• Uniform temperature control

• Quickly heat and dry samples, able to heat samples up to 200°C

• Stainless steel sus#304 inner oven and powder-coated steel plate exterior oven, corrosion resistant

• Low energy consumption, cost saving

• PID digtal display controller brings you accurate and reliable temperature control


Thermostatic drying oven has many applications in various fields, including science, research, and industry:

Baking: Thermostatic drying oven are frequently used to dry glassware after washing, which is a critical step in many experiments and processes. Drying glassware in an oven helps to remove the water residue completely and prevents any unwanted reaction caused by water droplets.

Recommended steps to dry glassware by using a thermostatic drying oven:

• Rinse the glassware with distilled water and detergent until they are clean.

• Shake off as much excess water as possible.

• Place the glassware on the shelves inside the oven, with sufficient space between them to allow for adequate airflow.

• Adjust the oven temperature and time settings, and then carefully shut the door.

• Once the drying process is complete, take the glassware out of the oven and let it cool down to ambient temperature before handling.

Dehydration: Thermostatic drying oven is often used to dehydrate samples, to remove moisture from a substance to a constant weight.

This process is essential in chemical, and pharmaceutical research, as well as environmental analysis.

Polymer curing: Thermostatic drying oven is used to cure polymers, resins, and other materials by heating them at a specific temperature for a particular period. Polymer curing is commonly used in the fabrication of composites, coatings and laminates materials.

Coating: Thermostatic drying oven is used in the application of coatings by heating the substrate to a particular temperature, applying the coating and then drying it in the oven.

In a summary, thermostatic drying ovens are a very versatile laboratory equipment and have many applications in different field.

Frequently asked questions

Q: What is thermostatic drying oven?

A: Thermostatic drying oven heat materials or dry them out to remove moisture. It is typically used in industrial settings to dry out parts, components, and materials. Additionally, they may be used to cure materials or to temper them.

Q: What is the temperature range for thermostatic drying oven?

A: The temperature range of a lab drying oven usually ranges from ambient temperature up to 200℃. Some ovens may have higher temperature ranges up to 300℃.

Q: What is forbidded to be placed in a thermostatic drying oven?

A: Inflammable, explosive or volatile specimen, corrosive & biological specimen, radioactive and toxic specimen, powder materials can’t be exposed in the oven, due to air circulation.
