Climatest Symor® is committed to provide high-level, competitively priced dry cabinets for integrated chips, with professional sales and technical support, Dry Cabinet for Integrated Chips are mainly used in mounting factories, and also for storage of optical fiber, such as CCD, micro-lens for WDM, image sensors, etc.
Model: TDU1436BFD-6
Capacity: 1436L
Humidity: <3%RH Automatic
Recovery time: Max. 30 min after open door 30 seconds then closed. (Ambient 25℃ 60%RH)
Shelves: 5pcs
Color: Dark Blue, ESD safe
Interior dimension: W1198*D682*H1723 MM
Exterior dimension: W1200*D710*H1910 MM
Description
Climatest Symor® Dry Cabinet for Integrated Chips provide an ultra-low humidity controlled environment, to prevent moisture absorption as well as rust and oxidation on MSD, moisture is the invisible killer that damages the products quality, this damage may be visible and only becomes aware of in the life cycle of the product, dry cabinets for integrated chips plays an important role in MSD protection, the cost of prevention is much lower than the cost of failure.
Dry Cabinet for Integrated Chips Specification
Mode# with F: ESD function, Dark Blue color. Mode# without F: No ESD function, off white color
Model |
Capacity |
Interior Dimension (W×D×H,mm) |
Exterior Dimension (W×D×H,mm) |
Average Power (W) |
Gross Weight (KG) |
Max. Load/shelf (KG) |
TDU320BD |
320L |
898*422*848 |
900*450*1010 |
10 |
70 |
80 |
TDU320BFD |
320L |
898*422*848 |
900*450*1010 |
10 |
70 |
80 |
TDU435BD |
435L |
898*572*848 |
900*600*1010 |
10 |
82 |
80 |
TDU435BFD |
435L |
898*572*848 |
900*600*1010 |
10 |
82 |
80 |
TDU540BD |
540L |
596*682*1298 |
598*710*1465 |
10 |
95 |
80 |
TDU540BFD |
540L |
596*682*1298 |
598*710*1465 |
10 |
95 |
80 |
TDU718BD |
718L |
596*682*1723 |
598*710*1910 |
15 |
105 |
80 |
TDU718BFD |
718L |
596*682*1723 |
598*710*1910 |
15 |
105 |
80 |
TDU870BD |
870L |
898*572*1698 |
900*600*1890 |
15 |
130 |
100 |
TDU870BFD |
870L |
898*572*1698 |
900*600*1890 |
15 |
130 |
100 |
TDU1436BD-4 |
1436L |
1198*682*1723 |
1200*710*1910 |
25 |
189 |
100 |
TDU1436BFD-4 |
1436L |
1198*682*1723 |
1200*710*1910 |
25 |
189 |
100 |
TDU1436BD-6 |
1436L |
1198*682*1723 |
1200*710*1910 |
25 |
189 |
100 |
TDU1436BFD-6 |
1436L |
1198*682*1723 |
1200*710*1910 |
25 |
189 |
100 |
Dry Cabinet for Integrated Chips Feature
·Adopts Switzerland original imported humidity & temperature sensor.
-This ensures high accuracy in use, this dry cabinets for integrated chips have memory function, no need to re-set after power failure.
·Made by 1.2mm thickness galvanized steel, with USA DuPont ESD painting.
-Reinforced structure design, excellent load-bearing, surface treatment with 18 painting processes, the static resistance value meets 106 -108Ω, also with strong corrosion resistance.
·3.2mm high intensity tempered glass window for better observation.
- Flat press zinc alloy lock, with perfect air tightness and anti-theft function, this dry cabinets for integrated chips sealing performance is excellent.
·With memory function, no need to re-set after power failure.
-The dry cabinets for integrated chips can automatically memorize the last setting value after power off, no need set again.
·Powerful dry unit with +15 years projected lifespan.
- The dry cabinets for integrated chips adopt 4A molecular sieve dry unit, the most advanced technique, it can be regenerated automatically, no need replacement.
·Universal castors installed at bottom, ESD safe.
- Reinforced PU castors are installed at the bottom of dry cabinets for integrated chips, front two with brakes for easy move and stop.
What are Climatest Symor® dry cabinets for integrated chips, dry cabinets for IC packages?
Climatest Symor® dry cabinets for integrated chips is designed to remove moisture from components, and rapidly recover to the setting value automatically, the dry cabinets suits wide application from electronics, laboratory to aviation, that requires humidity controlled storage, the LED controller monitors the whole humidifying and dehumidifying process, the desiccant can be regenerated without replacement, and the lifespan is +15 years.
How do dry cabinets for integrated chips influence the SMT production?
When assemble the components to the Printed Circuits Boards (PCB), the package is exposed to the high temperature environment, trace moisture easily enter into the components by diffusion, the absorbed moisture expand quickly inside, this result in damages, like wiring failure, popcorn and micro-cracking, even cracking to surface, these defects are not easy to be noticed in the early stage, the maintenance is troublesome and even waste of the assembly, It is crucial that these invisible, potential problems enter into the market, then faculty products return and complains.
IPC/JEDEC J-STD-033 standard specifies“Standard for Handling, Packing, Shipping and Use of Moisture/Reflow Sensitive Surface Mount Devices.”, it require low humidity storage for moisture sensitive components.
<3%RH series dehumidifying speed:
Under ambient 25 degree C, humidity 60%RH, open door 30 seconds and then closed, the humidity will recover to <3%RH within 30 minutes, see below curve:
Feature of dry cabinets for integrated chips
*All the models can maintain <3%RH automatic
*Wide range of dry cabinets with different sizes for selection
*Conforms to IPC/JEDEC J-STD-033 standard
*Dehumidifying semiconductor components to prevent popcorn/micro-cracking
*Options like over-humidity buzzer alarm, open door buzzer alarm, data logger
*ESD safe
Characteristics of dry cabinets for integrated chips characteristics
1.Module design: The dry cabinets for integrated chips adopt independent module design, from small spare parts, to temperature & humidity controller, control system and dry units, every module can be quickly replaced, simple maintenance, this greatly improve the maintenance efficiency.
2.Environment-friendly design: The latest module design, the dry cabinets for integrated chips can be directly upgraded, and the old system modules can be sent back to the original factory. Therefore, the machine will never be obsolete, also it does not produce waste pollution.The powerful electronic drying cabinet is designed for long-term use for more than 15 years.
3.Flexible design: Before purchase, users can add options on dry cabinets for integrated chips, like over-humidity buzzer alarm, data logger, open door buzzer alarm, three-color tower light, the flexible design offers customers more efficient selection.
